Twenty-one years ago, we began a quest.  You might call it a search and rescuemission; an all-out calling focused on uncovering and preserving as manydetails related to America’s early western vehicles as possible.  In the past two-plus decades, we’ve beenblessed to find a literal mountain of forgotten images, information, vehicles,and parts.  We’ve also been fortunate toassist a number of individuals and organizations seeking this type of authentic connection to our westernroots.

The materials we’ve collected have become an amazing foundation,confirming originality and directing us to even more areas of our horse drawnpast.  Time and again, the parts for somany of these puzzles have been flushed out. Like a covey of quail erupting from an otherwise ordinary fence row,these details can come fast and unexpected. There often seems to be no rhyme or reason as to what comes along or when...something shows up in the mail, we stumble across an unrelated tidbit whilefocused on a different area of research, or sometimes during a trip we happenacross a part of our past that no one ever knew existed.

It’s truly a rush to recognize a vehicle or part as an importantmissing link and watch the rest of the story come together.  With that said, one of the accounts I’ll besharing at Colonial Williamsburg this week involves us finding two small photosshowing a type of military wagon.  Atfirst, that’s all I could deduce. Actually, it appeared to be a supply wagon of some type.  The pair of old photos included a number of Escortwagon running gears surrounded by several Missouri mules.  One of the gears was topped with an enclosedwooden box that I had never seen before. For the moment, it was a mystery. Like a lot of the images we receive, though, I filed the photo but keptthe memory of it close at hand.

Reduced in size and resolution here, this incredibly rare image of a 100-plus-year-old Tool Wagon is giving us an even broader picture of known U.S. military vehicles.
Years later, I learned of some military-related correspondence whichincluded a set of blueprints for a wagon. First of all, original blueprints for any type of wooden wagon arescarce to say the least.  Second, whatwould you say the chances are that these blueprints would be a match to thephotos I’d happened upon years earlier?  Needle in a haystack, right?  Most of the time, I’d probably agree but,miracles happen every day.  Theblueprints turned out to be a dead-ringer for the photos.  Once again, separated pieces found their wayback together and now we have a very solid picture of an ultra-rare militarywagon.  So solid, we could completelyrebuild this history exactly as it was a hundred years ago.  Along with the blueprints came the officialname, “Tool Wagon.”  Knowing the propertitle has also opened numerous doors, each helping add even more detail to whathad previously been just a couple of old photos with no identity or immediatesense of value.

As it turns out, Tool wagons were in use inside America’s military asearly as the Civil War.  Militaryaccounts refer to the twentieth century version we ran across as a “tool box onan escort frame.”  It’s an aproposmoniker for this set of wheels.  Theenclosed box could be equipped with a wealth of materials including shovels,lanterns, hatchets, axes, levels, picks, crow bars, calking irons, paint,brushes, cross-cut saws, rope, twine, wire, wrenches, nails, screws, spikes,portable blacksmith outfits, carpenter’s and saddler’s tools, and more.

As I soon discovered, there were multiple types of Tool wagons beyond this dead axle configuration.  Spring hung Tool wagonswere also used.  They were similar to anambulance with drawers, lockers, and compartments for drafting, surveying,reconnaissance, and photographic gear. There was also a Pontoon Tool wagon designed to carry materials needed forcrossing rivers and large creeks.

Whether on the ranch or range, period chuck wagons were generally a custom-designed vehicle.  Studebaker was one of a select few major builders to cater to ranch wagon needs.
In a similar vein, lately, we’ve been making inroads into other unknowns.  With 2016 being the 150th Anniversary of Charles Goodnight's construction of the first chuckwagon, I thought I’d pass along a little teaser.  Over the years, a lot of discussions have taken place as to what that wagon looked like.  While we don’t have actual imagery of that legendary set of wheels, we have grown closer to understanding how the old wagon would have appeared.  It’s not been easy but, piece by piece, we’ve slowly been able to dig through enough early reports and documents to begin dividing fact from fiction.  Sometimes, a dead end in one direction can open up in another.  In other words, when we don’t know exactly what something looked like, coming at it from another angle can at least tell us what it didn’t look like.  Ultimately, these exercises placed alongside primary source documentation have produced enough fruit that one day soon we may be able to share even more about America's first chuck wagon.

In the meantime, we continue to roll along an incredibly historic road, looking for the lost and legendary parts of our wood-wheeled western heritage.  From rare logos and design specifications to original images and promotional samples, we're working hard to help bring it all back together in the Wheels That Won The West® Archives.
